VISUAL HEADLAMP ALIGNMENT SYSTEM ASSEMBLY OPERATION

10Answer: All lamps are legislated to be created equal, but this has proven not to be the case. Lamp intensities will vary from lamp to lamp. The

INDEX 1. GENERAL Pg. 3 1.1 “SCA 1 ISOColor ” INTRODUCTION 1.2 SYSTEM COMPONENTS 1.3 LASER WARNING 1.4 WARNING, EXPOSURE TO DIRECT SUNLIGHT 2.

1. GENERAL 1.1 INTRODUCTION The Model “SCA 1 ISOColor” Visual Headlamp Alignment System is an economical optical alignment tool that functions und

2. ASSEMBLY Inspect all components of the SCA 1 ISOColor system to assure that no damage has occurred during shipment, compare contents of package wi

Place a thick nylon bushing on the screw and insert screw through the holes provided at the top of the mast, place a thick nylon bushing on screw and

63. OPERATION PROCEDURES 3.1 PREPARATION, ALIGNMENT BAY(s) Prior to any headlamp alignment using the SCA 1 ISOColor, the floor slope of the bay

4. HEADLAMP ALIGNMENT 4.1 ALIGNMENT OF OPTICAL HEAD TO VEHICLE Place the SCA 1 ISOColor in front of the first headlamp to be aligned. Once the S

HV US Low Beam VOL .4 Degree Down (2.096 Inches) Aim Area 8• SAE LOW BEAM “VOL” (Visual Optical Left): Low beam lamps manufactured after 1999, so

“Calibration Required ONLY if Rear- LASER Adjustment Set Screw has been tampered with” Tools Required: Elevated Surface (wheel alignment, frame mach
